Modular Wash Bay PRO-S2
- 3000mm width by 3000mm depth wash area
- Two modular base sections
- Three 2.2m walls to minimise overspray
- Safe access via two galvanized anti-slip ramps
- Channels dirty water and debris into a dedicated solids collection tank
- Make water savings with the WPP10 filtration system
Where Sustainability Meets Affordability
KEY FEATURES
Compact-size Upgrade
The wash area of the WashPad PRO-S2 measures approximately 3000mm in width and 3000mm in depth, making it suitable when needing a bit more washing space.
Accessible Entry
Equipped with two galvanized anti-slip ramps as standard, ensuring safe and easy access for equipment. Additional ramps available.
Overspray Protection
Three-sided walls standing at 2200mm high walls to help minimize overspray during the cleaning operations.
Efficient Waste Management
The wash bay floor pan channels dirty water and solids towards a rear collection tank with three dams that retain solids while allowing water to filter through.
Automated Filtration
A float switch-activated diaphragm pump transfers water to the WPP10 Filtration Tank, where contaminants are filtered out, and the water is lightly chlorinated for reuse.
ADVANTAGES
Environmental Compliance
The closed-loop system recycles water, preventing contaminated runoff and aiding compliance with environmental regulations.
Cost-Efficiency
Reduces water usage, leading to lower water bills and potential savings on discharge licenses.
Modular and Portable
Designed for easy transportation, assembly, and disassembly, with a modular structure that can be tailored to specific applications.
Sustainability
Recycle 100% of the water used in the cleaning process with the WPP10 filtration tank.
The WashPad PRO-S2 Wash Bay is a self-contained, modular, eco-friendly cleaning system for small construction plant, equipment and tools.
WASHPAD PRO-S2: TECHNICAL SPECIFICATIONS |
|
|---|---|
| Wash Area | 3000mm x 3000mm |
| Total Dimensions | 3000mm x 4835mm |
| Filtration Tank Dimensions | 2810mm x 740mm x 990mm(H) |
| Max Load Capacity | 5000Kg |
| Wall Height | 2200mm |
| Total Dry Weight | 1290Kg |
| Diaphragm Pump | 0.054kW – 17L/minute |
| Booster Pump | 0.37kW – 5 to 40L/minute |
| Filtering System | WPP10 |
