Economic Septic Tank Installation

Two Chamber Septic Tank

Sewage Treatment For Rural Areas

In the UK, a septic tank is generally used on farms and houses where no mains sewage drainage is available. A cost effective septic tank installation is now available from Morclean to BS6297 standards.

The Morclean septic tank is a horizontal design and is more economical to install than a same capacity, cylindrical septic tank.

The septic tank is two chambers and a dividing wall that separates waste solids from waste liquids It has openings midway between the base, at the top of the tank. Standard anyway covers and lids are fitted to both chambers via a 600mm turret.

Sewage Access Covers

Sewage Access CoverPlease note: This item requires frames and sewage access covers covers (not included)

Due to the weights involved, covers and lids are expensive to transport and often cost more to ship than they are worth. We advise you source your own.

Covers and lids can be purchased from most builders merchants and below is a guide to assist you choosing the best type for the duty.

European Standard: BS EN 124
Size: 600mm x 450mm
Class A15 – Light Duty: Cars/Vans – 3 tonne loading
Class B125 – Medium Duty: Cars/Small Commercials – 17 tonne loading
Class D400 – Heavy Duty: Large Commercials/HGV – 38 tonnes loading

How a Septic Tank Works

When waste water and solids are flushed into the septic tank, the waste solid matter is retained within the first chamber and the waste water is allowed to pass through the second chamber to an irrigation system. A percolation test, as outlined in PPG4 and BS6297, will determine the size of the irrigation system required.

A septic tank generally has a capacity between 4,000 to 7,500 litres and is connected to an inlet pipe of waste water at one end and a septic drain field at the other end. The T pipe connections allows liquid ingress and egress, leaving any crust undisturbed.

Waste water flows into the tank, solids settle in the first chamber and scum floats to the surface. Anaerobic action digests the solids, reducing the volume. Further settlement takes place in the second chamber when the liquid outflow passes through the opening in the dividing wall. The settlement in the second chamber produces a relatively clear outflow through the outlet into the drain field.

The few remaining impurities will percolate through the soil and return to the groundwater via evaporation as well as taken up through the roots of plants and trees, assisted by  pipe work or drainage system installations.

Undecomposed solid waste must be removed from a septic tank periodically or it will overfill and pollute the drainage field with undecomposed wastewater.

acrobat-reader-50x50EA – PPG 4 (254Kb)
Guidelines for treatment and disposal of sewage where no foul sewer is available.


The EA and SEPA Pollution Prevention Guidelines (PPG) which are jointly produced by the Environment Agency for England and Wales, the Scottish Environment Protection Agency, and the Environment and Heritage Service for Northern Ireland (Ref PPG3 / PPG13 / PPG4 / PPG 14) suggest that Class 2 wash bay silt traps and interceptors should be connected only to a mains foul drain, and Class 1 separators to surface drain.

The above assumes you have the consent to connect any outflow to a suitable drain as per the appropriate PPG Guideline. While we always endeavour to provide best advice and accurate information, it the responsibility of the client and/or landowner to comply with the law. Following any guideline doesn’t remove your responsibility to comply with the law and prevent pollution from your activities. Causing or allowing pollution is a criminal offence; compliance with any guidance isn’t a defence. You should make sure that the references to other sources of guidance are still current.

Avoid problems with a septic tank by following this guide.

  • Pouring excessive quantities of cooking oils and grease may cause blocking of the inlet drains
  • As oils and grease are often difficult to degrade, problems with odour can occur
  • High volumes of oils and grease can cause difficulties with the periodic emptying
  • Non-biodegradable items e.g. sanitary towels and cotton buds will rapidly fill or clog a septic tank
  • Some chemicals can damage the anaerobic bacterial working of a septic tank: pesticides, herbicides, bleach, caustic soda, paints & solvents
  • Vehicle wash water should NOT outflow to a septic tank
  • Excessive water engress could overload the system and cause it to fail.
  • Check the toilet paper. Some varieties are not suitable for disposal in a septic tank as they did not deteriorate sufficiently

Checking for plumbing leaks and practicing water conservation will help the system’s operation.

Septic Tank Maintenance

As with all septic tanks, the chambers will require a de-sludge to remove the solids which settle and gradually fill the tank, reducing its efficiency.

The horizontal design allows for easier maintenance access.

The maintenance timescale depends on several things:

  • input of solids
  • tank volume
  • quantity of indigestible solids
  • ambient temperature

Periodic inspection and pumping of the septic tank is essential.
